Central Fume Extractor Welding System (Fume Collector)

---

Industrial Fume Extractor Welding System

Heavy industrial metal fabrication—including manual stick welding, gas shielded MIG/MAG processes, TIG welding, and plasma cutting—generates hazardous fume plumes containing fine metal oxides, toxic gases, and sub-micron particulate matter. Implementing an advanced Fume Extractor Welding System supplied by Thermatech provides essential source-capture protection, safeguarding welder health while helping plants meet stringent environmental and occupational safety standards.

The Industrial Fume Extractor Welding System is designed to extract pollutants directly at the source before dangerous fumes enter the operator’s breathing zone or migrate across the facility. Utilizing a 360-degree flexible extraction arm, the Fume Extractor Welding System easily adjusts to any welding angle or position, providing uninterrupted suction power with minimal manual adjustment during complex fabrication runs.

Furthermore, each Industrial Fume Extractor Welding System features an intelligent control unit paired with an automatic pulse-jet filter cleaning system. Compressed air bursts dislodge accumulated dust cakes from the high-efficiency nanofiber cartridges into a removable collection bin, ensuring steady static pressure and continuous air volume flow. Whether configured as a mobile unit for multi-bay workshops or integrated with automated robotic welding cells, this equipment delivers long-term durability, low operational noise, and exceptional energy efficiency.

Technical Advantages of Industrial Fume Extractor Welding System

Designed to deliver clean workshop air and optimal health protection across demanding production lines, our Fume Extractor Welding System offers significant operational benefits:

• 99.9% Source-Capture Filtration Efficiency: The Fume Extractor Welding System traps hazardous sub-micron metallic dust, weld fumes, and PM2.5 airborne particles at the source.
• 360-Degree Positional Extraction Arm: Smooth articulation and stable counterbalancing allow operators to position the hood quickly for continuous fume capture.
• Automated Pulse-Jet Cartridge Cleaning: High-pressure reverse air pulses clear filter surfaces automatically, maintaining peak airflow and extending filter cartridge lifespans.
• Heavy-Duty Mobility & Low Noise Output: Built with industrial powder-coated steel housing and lockable heavy-duty casters, combining quiet fan performance with versatile shop floor mobility.

Our Fume Collector System Eliminates 99% Of Metal Welding/Cutting Particles And Fumes Of Sizes PM0.3 Or Larger.



Remove Fumes and Smoke From Your Work Place

Developed specifically for dust and fume filtration in welding, cutting, grinding and polishing. Never see smoke in your workspace again.

Compact design that allows filter unit, motorized fan, control system as well as pre-treatment device to be all in one single unit, saving you vital space.

Uses premium grade PTFE (Poly Tetra Fluoro Ethylene) coated filter cartridges to effectively remove dust and welding fumes.

Collector Unit Features

Guiding plate at air inlet helps to evenly spread dusty air flow, reduce air resistance, and prevent cartridges from damage caused by large particles.

Proprietary easy-to-install cartridge and mechanical lifting device of dust bin makes maintenance very simple. Also a cone inside the cartridge that enhances dedusting efficiency by 30% and more.

Dis-mounting cartridges is by a simple rotation of the handle in replacement and maintenance. Vertical placement of cartridge makes pulse-jet dedusting more effective so as to improve cartridge use life. Pulse-jet dedusting can be set up based on time interval or pressure difference.

PLC control system offers the worker a user-friendly experience. Noise damping design that minimizes noise in the workplace.

Cartridge Filter Features

Highly efficient PTFE film which performs at least 3-5 times more than a traditional filter.

99.0% filtration efficiency for the dust that is more than 0.3 micron.

Service life can reach 8000hrs, which is twice longer than the traditional filter.

Custom Hood

Exhaust System

Our engineers will design and build a custom hood exhaust system based on the fixed locations of your welding stations, cutting machines, or workbenches of any size.

We use only superior quality Galvanized Steel Spiral ducts and/or Stainless Steel Long Seam ducts. Available in a variety of sizes, we ensure that you get an efficient, sturdy and long lasting ducted exhaust system with minimal pressure loss.
