Submerge Wire & Flux (Sorex Brand) – SF-65 x SW-M12K

Submerge Wire & Flux (Sorex Brand)- SF-65 x SW-M12K

DESCRIPTION :
SF-65 is a neutral flux designed for multi-pass groove welds with excellent bead appearance,
easy slag removal good porosity resistance and in deep groove applications.
It produces good impact property and minimum 500 N/mm2 tensile when used with SW-M12K wire.

APPLICATIONS :
Typical applications include pressure vessels, shipbuilding and steel structures.

NOTE ON USAGE :

1. Re-dry the flux at 350°C for 60 minutes prior to use.
2. Lower current is recommended for welding first pass.
3. It can be used for either single arc AC or DC welding or multiple arc DC lead, AC trail arc.

TYPICAL CHEMICAL COMPOSITION OF WELD METAL (wt%) :

TYPICAL MECHANICAL PROPERTIES OF WELD METAL :

TYPICAL IMPACT VALUES (with SW-M12K Wire) :

APPROVALS :
ABS. LR
