Description
Thermatech Handheld Laser Welding Machine
• The fiber laser welding machine is equipped with a touchscreen control panel and a laser welding digital wire feeding system (touchscreen-controlled) with a Thai-language user interface for easy and intuitive operation.
• The laser welding system is available with fiber laser power options of 1,500 W, 2,000 W, and 3,000 W.
• Available with single-wire and dual-wire laser welding feeding systems. The dual-wire laser welding system enables welding of thicker materials and produces weld beads that comply with WPS (Welding Procedure Specification) standards.
• Suitable for laser welding of sheet metal, including stainless steel, carbon steel, aluminum, and other metals.
• Equipped with a water-cooled laser welding gun, allowing stable and continuous laser welding operations.
• 3-in-1 laser welding multifunction capability: laser welding, laser cutting, and laser rust/oxide cleaning in one system.
• Key advantages of laser welding technology: high welding speed, reduced cycle time, minimized material distortion, reduced post-weld finishing, and improved overall productivity.
• Professional laser welding training and technical consultation are provided until operators are fully proficient in using the fiber laser welding machine.
Specification
| Model | TMT-FCW1000 |
|---|---|
| Laser Source | YB: Fiber Laser |
| Welding Mode | Continuous |
| Laser wavelength | 1070 nm. |
| Max. laser Power | 1000 Watt. |
| Repeat frequency | 5 – 10 kHz. |
| Range of power | 1 – 100 % Adjustable |
| Welding thickness | 0.5 – 3 mm. (Depends on materials) |
| Welding penetration | 0.5 – 2 mm. (Depends on materials) |
| Repeat precision | ± 0.01 mm. |
| Fiber Cable length | 10 meter |
| Fiber interface | QBH |
| Laser module life | >100,000 Hrs. |
| Cooling Methode | Internal water chiller |
| Power consumption | <=3kw |
| Power Input | 220 Volt 1 Phase 50 Hz. – 30Amp. |
- Description
-
Thermatech Handheld Laser Welding Machine
• The fiber laser welding machine is equipped with a touchscreen control panel and a laser welding digital wire feeding system (touchscreen-controlled) with a Thai-language user interface for easy and intuitive operation.
• The laser welding system is available with fiber laser power options of 1,500 W, 2,000 W, and 3,000 W.
• Available with single-wire and dual-wire laser welding feeding systems. The dual-wire laser welding system enables welding of thicker materials and produces weld beads that comply with WPS (Welding Procedure Specification) standards.
• Suitable for laser welding of sheet metal, including stainless steel, carbon steel, aluminum, and other metals.
• Equipped with a water-cooled laser welding gun, allowing stable and continuous laser welding operations.
• 3-in-1 laser welding multifunction capability: laser welding, laser cutting, and laser rust/oxide cleaning in one system.
• Key advantages of laser welding technology: high welding speed, reduced cycle time, minimized material distortion, reduced post-weld finishing, and improved overall productivity.
• Professional laser welding training and technical consultation are provided until operators are fully proficient in using the fiber laser welding machine.
Specification
Model TMT-FCW1000 Laser Source YB: Fiber Laser Welding Mode Continuous Laser wavelength 1070 nm. Max. laser Power 1000 Watt. Repeat frequency 5 – 10 kHz. Range of power 1 – 100 % Adjustable Welding thickness 0.5 – 3 mm. (Depends on materials) Welding penetration 0.5 – 2 mm. (Depends on materials) Repeat precision ± 0.01 mm. Fiber Cable length 10 meter Fiber interface QBH Laser module life >100,000 Hrs. Cooling Methode Internal water chiller Power consumption <=3kw Power Input 220 Volt 1 Phase 50 Hz. – 30Amp. - Gallery
-
- Video
-
Review: Fiber Laser Welding Machine
The Thermatech Fiber Laser Welding Machine, Handheld Fiber Laser Welding Machine 3 in 1 with 3,000W laser power, is designed to meet the demands of industrial laser welding applications. Equipped with a dual wire feeding system, this laser welding machine produces thick, strong, and consistent weld beads that comply with WPS (Welding Procedure Specification) standards, ensuring reliability and strength for industrial-level welding tasks.
The fiber laser welding system is available in multiple power options, including 1,500 W, 2,000 W, and 3,000 W, making it suitable for a wide range of laser welding applications. It is ideal for sheet metal welding of stainless steel, carbon steel, aluminum, and other metals.
Key Features of the Thermatech Laser Welding Machine
- 3-in-1 laser welding machine with multifunction capabilities: laser welding, laser cutting, and laser rust/oxide cleaning in a single system
- High-speed laser welding for thin sheet metals, reducing cycle time and minimizing thermal distortion
- Smooth and aesthetically pleasing weld seams, reducing grinding and post-weld finishing processes and improving overall productivity
- Advanced fiber laser technology delivers stable, precise, and consistent laser energy
- The laser welding machine can be easily integrated with an automatic wire feeding system
- Guaranteed satisfaction in terms of both quality and cost-effectiveness
- Robust, precise, and durable construction, designed for continuous operation in industrial environments
After-Sales Service
- Online Service for initial troubleshooting and technical support
- On-site service provided by professional engineers from Thermal Mechanics, ensuring reliable after-sales support and long-term performance
