Thermatech SAW welding machine model MZ-630
Thermatech SAW welding machine model MZ-630
- Thyristor control technology, with simple circuit and convenient maintenance.
- Suitable for SAW, and Carbon Gouging welding etc.
- Excellent power grid compensation capacity and the current variation rate in 1% when voltage variation rate is within + 10%.
- The control line minimizes design and greatly reduces the failure rate of the broken line.
- Super-widely current adjustment range.
Specification
| Model | MZ-630 |
| Input Voltage/Frequency Three phase | 3ø380V+15%50-60Hz |
| No-load voltage (V) | 78 |
| Rated welding voltage (V) | 44 |
| Rated welding current (A) | 630 |
| Current adjustment range (A) | 100-630 |
| Rated input power (KVA) | 49.3 |
| Rated input power (A) | 75 |
| Rated duty cycle (%) | 100 |
| Efficiency | 0.85 |
| Power factor | 0.9 |
| Dimension L x W x H (mm) | 950x580x850 |
| Net weight (kg) | 285 |
